GB
7.2 Crosscut 90° and turntable 0° - 45°
(Fig. 1 – 3, 31)
The crosscut saw can be used to make angular cuts
of 0°- 52° to the left and 0 – 60° to the right relative to
the stop rail.
Release the turntable (17) by slackening the
locking grip (14).
Press the locking lever (13), turn the turntable (17)
and scale pointer (15) to the desired angular
setting on the dial (16) and lock into place with
the locking grip (14). The saw has locking
positions at angular positions of -45°, -30°, -22,5°,
-15°, 0°, 15°, 22,5°, 30°, 45° and 60° at which the
locking lever can be engaged.
Retighten the locking grip (14) to secure the
turntable (17) in place.
Cut as described under section 7.1.
7.3 Miter cut 0°- 45° and turntable 0°
(Fig. 1 – 3, 32)
The crosscut saw can be used to make miter cuts of
0° - 45° in relation to the work surface.
Remove the clamping device (8) if necessary or fit
it on the opposite side of the fixed saw bench
(18).
Move the machine head (4) to its upper position.
Fasten the turntable (17) in 0° position.
Undo the locking screw (22) and use the handle
(1) to tilt the machine head (4) to the left until the
pointer (20) points to the required angle on the
scale (19).
Retighten the locking screw (22) and make the cut
as described in section 7.1.
7.4 Miter cut 0°- 45° and turntable 0° - 45°
(Fig. 1 – 3, 33)
The crosscut saw can be used to make miter cuts of
0°- 45° to the left relative to the work surface and, at
the same time, 0° - 52° to the left or 0° - 60° to the
right of the stop rail (double miter cut).
Remove the clamping device (8) if necessary or fit
it on the opposite side of the fixed saw bench
(18).
Move the machine head (4) to its upper position.
Release the turntable (17) by slackening the
locking grip (14).
Use the handle (1) to adjust the turntable (17) to
the angle required (in this connection see also
section 7.2).
Retighten the locking grip (14) to secure the
turntable in place.
Undo the locking screw (22) and use the handle
(1) to tilt the machine head (4) to the left until it
coincides with the required angle value (in this
connection see also section 7.3).
Re-tighten the locking screw (22).
26
08.04.2009 7:50 Uhr Seite 26
Cut as described under section 7.1.
7.5 Limiting the cutting depth (Fig. 34)
The cutting depth can be infinitely adjusted using
the screw (34). Undo the knurled nut on the screw
(34) and move the stop for limiting the cutting
depth (35) to the outside. Set the required cutting
depth by tightening or undoing the screw (34) and
then tighten the knurled nut on the screw (34).
Check the adjustment by making a test cut.
7.6 Chip collection box (Fig. 35 – 36 / Item 23)
The saw is equipped with a chip collection box (23)
for sawdust and chips. The chip collection box (23)
can be connected to the extractor adaptor (33).
To empty the chip collection box (23), open it as
shown in Fig. 37 and carefully tap it to empty the
contents.
A suitable dust extraction device may also be
connected to the extractor adapter (33).
7.7 Changing the saw blade (Fig. 1, 37 – 40)
Remove the power plug!
Swing the machine head (4) upwards and lock it
in this position using the locking pin (27).
Press the release lever (3) and swing up the saw
blade guard (6) to the point where the recess in
the saw blade guard (6) is above the flange bolt
(39).
Press the saw shaft lock (5) with one hand while
holding the wrench (P) on the flange bolt (39)
with the other.
Firmly press on the saw shaft lock (5) and slowly
rotate the flange bolt (39) in clockwise direction.
The saw shaft lock (5) engages after no more
than one rotation.
Now, using a little more force, slacken the flange
bolt (39) in the clockwise direction.
Undo the flange bolt (39) and remove it and them
take off the outer flange (40).
Take the saw blade (7) off the inner flange and
pull it out downwards.
Carefully clean the flange bolt (39), outer flange
(40) and inner flange.
Fit and fasten the new saw blade (7) in reverse
order.
Important. The cutting angle of the teeth, in other
words the direction of rotation of the saw blade
(7) must coincide with the direction of the arrow
on the housing.
Check to make sure that all safety devices are
properly mounted and in good working condition
before you begin working with the saw again.
Important. Every time that you change the saw
blade, check to see that it spins freely in the table
