Please note: If you wish to change from one operating mode into another, you either have to switch off the
lamp/activate Blackout-mode or unplug the projector from the mains and plug it again.

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.

DMX-protocol

Control channel 1 - Iris
DMX-value Feature
0 - 255 Gradual adjustment from Min. to Max.
Control channel 2 - Colour-wheel 1
Linear colour change following the movement of the slider. In this way you can stop the colour-wheel in any
position.
DMX-value Feature
0-15 Open/white
16-31 Red
32-47 Yellos
48-64 Magenta
65-81 Green
82-97 Orange
98-113 Blue
114 Violet
193-255 Rainbow effect with increasing speed
Control channel 3 - Shutter, Strobe
DMX-value Feature
0-40 Shutter closed
41-122 Dimmer control (Shutter open)
123-139 No function (Shutter open)
140-240 Strobe-effect with increasing speed
241-255 No function (Shutter open)
Control channel 4 - Colour-wheel 2
DMX-value Feature
100 Correction filter 3200 K
150 Correction filter 6000 K

CLEANING AND MAINTENANCE

The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
