Operation; Operation Code Lock; Door Release; Light Switching - TCS codelock12 Produktinformation

Operation code lock

Door release

Basic mode
1 Enter access code
Correct entry
Incorrect entry, unknown access
code

Light switching

Basic mode
1 Press #-button

Operation power supply and control unit

Enable system programming mode
Avoid water entering the device!
!
Do not use any aggressive or abrasive cleaning agents!
Clean the device using a dry or slightly moist cloth.
More persistent dirt can be removed using a mild household cleaner.
TCS TürControlSysteme AG • Geschwister-Scholl-Str. 7 • 39307 Genthin
Phone.: +49 39 33 / 87 99 10 • Fax: +49 39 33 / 87 99 11 • www.tcs-germany.com
30

Operation

• Enter access code.
• Confirm with #-button.
A positive acknowledgement tone sounds, LED
lights up green.
The door opener is released.
A negative acknowledgement tone (triple beeps)
sounds at activation of the #-button, LED lights up
red.
The code can be entered only 3 times incorrectly,
then the code entry is blocked for 2 min.
Start again from the beginning.
• Press #-button without previous code entry.
Prerequisite is that the function has been activated (see Programming and
Define options)

Cleaning

Disable system programming mode
