Opening the case
1. The lower panel is connected with the aluminum profile section by two screws. Remove
both screws with the aid of a suitable screwdriver.
Slide the front panel down and remove it.
2. Feed the cables through the cable duct.
3. Securely mount the device on the wall with suitable bolts using the attachment holes
(see overview).
!
The screw head height may be max. 3 mm!
!
Take care not to pinch the cables.
Closing the casing
1. Slide front panel upwards under the light strip.
During the insertion of the front panel, ensure that the contact pins are guided into
!
the sockets and are not damaged.
2. Attach the lower panel again with both belonging screws.
Line diameter
We suggest a wire diameter of minimum 0.8 mm for :BUS-lines and power supply. (Code
lock, screwed terminal: Connection diameter 0.3 -1.4 mm possible).
Notes
Use the small screwdriver supplied to connect the lines and prevent damage to the
!
device.
ATTENTION! The internal resistance of the door opener must not be lower then
!
6 ohm!
Connection
1. Strip the insulation from the line ends.
2. Connect the lines in accordance with the installation overview / connection diagram.
