Device Overview Code Lock; Device Overview Power Supply And Control Unit - TCS codelock12 Produktinformation

Two coloured
LED
Key pad with
12 buttons
Front panel

Device overview power supply and control unit

Light switching connection
Mains supply
connection
TCS TürControlSysteme AG • Geschwister-Scholl-Str. 7 • 39307 Genthin
Phone.: +49 39 33 / 87 99 10 • Fax: +49 39 33 / 87 99 11 • www.tcs-germany.com
22

Device overview code lock

Door release connection
TCS:BUS connection
Potentiometer
Door release
Potentiometer
Light switch time
Run/Prog button
Run/Prog indi-
cation (LED)
Subject to change without notice.
PI_PZF5000_Art0018993_1v0.doc
04/2007
Top panel
Connection terminal
Light strip
Cable duct
Attachment
holes
Lower panel
