Additional Functions - TCS codelock12 Produktinformation

Power supply and control unit
Power supply
Switching the system
mode
Terminals for a, b and
P

Additional functions

Code lock
Acoustic signalling of the
button actuation
Acoustic signalling of the
code identification
Optical signalling of the
code identification
Acoustic and optical ack-
nowledge on receiving of
a short door opener pro-
tocol
Optical signalling of the
programming mode
Illuminated buttons
Change of data records
and parameters
EEPROM memory
Power supply and control unit
Overload protection for P
wire
Internal light switch relay For triggering light control units 24 V / 1 A
Internal door release re-
lay
Door release time
Light switch time
Single voice channel
TCS TürControlSysteme AG • Geschwister-Scholl-Str. 7 • 39307 Genthin
Phone.: +49 39 33 / 87 99 10 • Fax: +49 39 33 / 87 99 11 • www.tcs-germany.com
21
24 V DC (for TCS:BUS)
Switching between system operating and programming mode,
LED indication
Short circuit protected
Using integrated piezoelectric buzzer, deactivatable
Using integrated piezoelectric buzzer.
• Positive acknowledgement tone (acoustic signal, single
beep) on acknowledgement of the code number, duration is
deactivatable / adjustable
• Negative acknowledgement tone (triple beeps) on rejection
Using two-color LED
• Lights up green on acknowledgement of the code number
(deactivatable, duration adjustable)
• Lights up red on rejection
• Lights up red on blocking after incorrect entry of code three
times (duration approx. 2 min)
By option Accept door opener protocols (cp. Programming,
page 28, 2f)
Two-colored LED flashes green
Indirect, blue
AS-addresse, R-contact switch time and factory settings
manually programmable
All programmed data records and parameters are stored in the
EEPROM.
If the maximum load limit (110 mA) is exceeded the integrated
fuse switches the output off. After removal of the overload and
cooling down of the fuse the output will automatically be
switched back on.
12 V, 50/60 Hz / 2 A
(for door opener not less than 6 ohm)
Manually adjustable, from 0.8 sec to 8 sec
Manually adjustable, from 0.8 sec to 5 min
Communication between front-door and in-house station over
more than one subsystem is not possible.
Subject to change without notice.
