Programming - TCS codelock12 Produktinformation

Programming

2a
Access code define
or change
First access code
Second access code
etc.
2b Activate or deactivate
R-contact for a code
2c Define transmission
protocol at code entry
2d Delete data record
for a predetermined mem-
ory location
2e Enter AS address
2f Define options
2g LED lighting duration
TCS TürControlSysteme AG • Geschwister-Scholl-Str. 7 • 39307 Genthin
Phone.: +49 39 33 / 87 99 10 • Fax: +49 39 33 / 87 99 11 • www.tcs-germany.com
28
Entry: * 0 # SpNr1 # access code # access code #
Entry: * 0 # SpNr2 # access code # access code #
SpNr = 1 to 10
Max. access code six-digit
Changing the old code by overwriting with the new code.
Entry: * 1 # SpNr # R #
SpNr = 1 to 10
(WE = 1 for SpNr 1 to 10)
R = 1 ON
0 OFF (R-contact without function)
Entry: * 2 # SpNr # P #
SpNr = 1 to 10
(WE = 0 for SpNr 1 to 10)
P = 0 (door opener protocol with own AS address)
1 (Control Function 1 with own serial number)
6 (Control Function SpNr with own serial number)
7 (Do not transmit any protocol)
Entry: * 3 # SpNr #
SpNr = 1 to 10
(Transmits door opener protocol with AS address, R-contact switches
and data record inactive)
Entry: * 4 # AS-Adresse #
AS address = 0 bis 63
(WE = 0)
Entry: * 5 # option # value #
Option:
0 Transmit light switching protocol
1 Accept door opener protocols
2 Rest position R-contact
3 Acoustic feedback buttons
4 Programming mode possible only
after programming mode of the sys-
tem has been switched on at the
power supply and control unit.
ATTENTION: Factory settings apply for standalone operation. In
order to increase the security, option 4 should be activated in
!
BUS operation (i.e. set value = 1), so that the programming re-
quires access to the power supply and control unit.
Entry: * 6 # value #
Value = Duration adjustable in 128 msec steps, 0 to 250 times
(WE = 255, use value of the R-contact!)
R – R-contact function
P – Protocol selection
Value:
0 = No, 1 = Yes (WE = 1)
0 = No, 1 = Yes (WE = 1)
0 = Off,
1 = switched
0 = Off, 1 = On
0 = No, 1 = Yes (WE = 0)
Subject to change without notice.
PI_PZF5000_Art0018993_1v0.doc
04/2007
(WE = 0)
(WE = 1)
