Setup Power Supply And Control Unit - TCS codelock12 Produktinformation

Transmit light switching protocol
Rest position of the R-contact
Central mode
st
1 access code (at memory location
number 1)
st
1 access code / parameter
(at memory location number 1)
nd th
2 - 10 access code
(at memory location number 2 to 10)
nd th
2 - 10 access code / parameter
(at memory location number 2 to 10)
Master code

Setup power supply and control unit

Setup
door release time:
LED goes ON
Setup time
Enable/disable system
programming mode
Setup light switch time:
LED illuminates
Setup time
Enable/disable system
programming mode
Legend for settings, programming, operation
briefly press key
press key until ...
release the key
TCS TürControlSysteme AG • Geschwister-Scholl-Str. 7 • 39307 Genthin
Phone.: +49 39 33 / 87 99 10 • Fax: +49 39 33 / 87 99 11 • www.tcs-germany.com
26
active (= 1)
OFF (= 0)
OFF (= 0)
111
Transmits door opener protocoll with AS address,
R-contact switches and data record active
Not assigned
Transmits door opener protocoll with AS address,
R-contact switches and data record inactive
123456
–: min. 0,8 sec Biefly press key
+: max. 8 sec RUN/PROG
–: min. 0,8 sec Biefly press key
+: max. 5 min RUN/PROG
LED flashes slowly
LED is ON
continue
LED flashes Biefly press key
slowly RUN/PROG
LED flashes Biefly press key
slowly RUN/PROG
Subject to change without notice.
PI_PZF5000_Art0018993_1v0.doc
04/2007
LED illuminates
LED illuminates
