Safety Notices; Terms - TCS codelock12 Produktinformation

Assembly, installation, and commissioning must only be carried out by a qualified elec-
!
trician!
For work on systems with 230 V AC mains voltage the safety requirements of DIN VDE
0100 must be observed.
When installing TCS:BUS systems the general safety rules for telecommunication systems
in accordance with VDE 0800 must be observed:
• separate cabling for high and low voltage lines,
• minimum distance of 10 cm for joint cabling arrangements,
• use of separators between high and low voltage lines in joint cable ducts,
• use of standard telecommunication cables, e. g. J-Y (St) Y with 0.8 mm cross section,
• existing cables (modernisation) with different cross sections may be used whilst taking
account of the loop resistance.
Suitable lightning protection must ensure that a voltage of 32 V DC will not be ex-
!
ceeded at the TCS:BUS wires a and b.
Basic mode
Programming
mode
Master code
Access code
TCS TürControlSysteme AG • Geschwister-Scholl-Str. 7 • 39307 Genthin
Phone.: +49 39 33 / 87 99 10 • Fax: +49 39 33 / 87 99 11 • www.tcs-germany.com

Safety notices

The system in normal operation. If changes should be made, the
device is to be set to the programming mode.
Operating state, in which input and change of the access codes,
the master code and further basic settings are possible (directly on
the device).
Max. six-digit security code for the activation of the programming
mode of the device
As-delivered condition: 123456.
Max. six-digit security code for the activation of the code lock
(e.g. direct release of the door opener).
19

Terms

Subject to change without notice.
