Installation Overview- Connection Diagram; Technical Data - TCS codelock12 Produktinformation

Code AZF50000
lock
Power NBV2001
supply
and
control
unit
Door opener is not included in the scope of delivery.
A FAA1100 can be connected optionally at the termals R and P at AZF50000.
To ensure the manipulation security prefer a connection of a door opener with the
!
NBV2001 in accordance with the installation overview– connection diagram.
Case
Dimensions (in mm)
Assembly
Weight
Operating temperature range
Input current
Maximum input current
Output current
Maximum Output current
Electromagnetic compatibility
(EMC);
Radio interference suppression
Supply voltage
3-wire technology required.
TCS TürControlSysteme AG • Geschwister-Scholl-Str. 7 • 39307 Genthin
Phone.: +49 39 33 / 87 99 10 • Fax: +49 39 33 / 87 99 11 • www.tcs-germany.com
Installation overview– connection diagram

Technical data

Front-door station
AZF50000
aluminium anodised nature;
front panel anodised nature
or grey
H 114 x W 88 x D 12 (19)
flush-mounting
200 g
-20 °C ... 50 °C
I(a) = 0,4 mA, I(P) = 14 mA
I(Pmax) = 59 mA
23
Power supply and control unit
plastic
H 90 x W 70 x D 70 (4 TE)
DIN EN 50022
(DIN-RAIL Cabinet)
475 g
0 °C ... + 40 °C
I(a) = 40 mA
I(P) = 60 mA
I(Pmax) = 700 mA (for:1 min Last/10
min break between 2 maximum loads)
in accordance with EN 50081 and EN
50082-2;
in accordance with EN 55011
230 V, 50 Hz
Subject to change without notice.
PI_PZF5000_Art0018993_1v0.doc
04/2007
