BREMSBAUGRUPPE UND GESTÄNGE
Item Order Description
No. No.
1 644647 Brake Tube
2 645103 Brake Lever
3 422155 Handle Grip
4 902314 Spacer
5 263500 Retainer - External
6 725688 Bracket – Brake Support Rt.
7 725689 Bracket – Brake Support Lt.
8 725666 Brake Arm Rt.
9 725667 Brake Arm Lt.
Item Order
No. No.
10 782331
11 257030
12 260608
13 253192
14 253035
15 253193
16 183894
17 250258
18 253020
48
Description
Strap – Brake Linkage
Washer
Ring Cotter
Whiz Bolt
Whiz Nut
Whiz Bolt
Switch - Brake
Machine Screw
Whiz Nut
13011
