ANTRIEBSAGGREGATBAUGRUPPE UND
Item Order Description
No. No.
1 391491 Integrated Transmission Rt.
(includes items 3-12)
2 391490 Integrated Transmission Lt.
(includes items 3-12)
3 130630 Pulley
4 281668 Square Key
5 130431 Fan
6 130632 Fan Spacer
7 253070 Whiz Nut
8 130618 Control Lever
130619 Spring - Return
9 130610 Breather/Dipstick
10 130605 Filter HTE/HTJ
130606 Filter Plug
11 281845 Woodruff Key
12 253992 Lock Nut
13 824458 Hub - Tapered
14 776156 Bracket – Tension Strap
15 902293 Spacer - Integrated
16 243575 Bolt
17 253067 Flange Nut - Spiral Loc
18 253203 Whiz Bolt
19 253043 Whiz Nut
20 381938 Belt
21 415545 Sheave
22 281582 Square Key
23 388750 Clutch
24 257422 Lock Washer
25 243470 Bolt
26 725123 Bracket – Anti Rotation
27 422088 Cover – Clutch Bracket
28 824478 Idler Arm Assembly
includes items 29 & 30)
29 121756 Oilite Bearing
30 121650 Bearing Pedestal
31 284428 Spring – Torsion LH
32 257040 Washer
33 243360 Bolt
34 257062 Washer - SAE
35 393195 Idler Pulley
LENKSÄULENBAUGRUPPE
46
Item Order Description
No. No.
36 243575 Bolt
37 253066 Whiz Nut
38 776158 Arm – Neutral Return
39 253191 Whiz Bol
40 253035 Whiz Nut
41 780175 Rod – Steering Linkage
42 265615 Ball Joint - RH Thread
43 254441 Nut - RH Thread
44 265616 Ball Joint - LH Thread
45 254444 Nut - LH Thread
46 253038 Whiz Nut
47 605745 Steering Lever Assembly
(includes items 48 & 49)
48 422179 Lever Grip - Foam
49 422095 Vinyl Cap
50 643926 Mount – Steering Lever
51 253195 Whiz Bolt
52 253470 Nut - Nylon Insert
53 604856 Steering Pivot Assembly Rt.
(includes items 55-58)
54 604857 Steering Pivot Assembly Lt.
(includes items 55-58)
55 422559 Bearing Sleeve w/Flange
56 422556 Bearing Sleeve w/Flange
57 422557 Bearing Sleeve
58 243197 Bolt
59 283324 Spring – Compression
60 257063 Nylon Washer
61 720160 Mount – Steering Switch Rt.
62 720161 Mount – Steering Switch Lt.
63 183860 Safety Switch
64 250318 Machine Screw
65 254400 Nut
66 253176 Whiz Bolt
67 253025 Whiz Nut
68 729730 Bracket – Damper Mount Rt.
69 729731 Bracket – Damper Mount Lt.
70 265680 Ball Stud
71 285032 Damper
72 253192 Whiz Bolt
73 729733 Bracket - Belt Tensioner
