Read installation and operating instructions in their
entirety before installing the heat meter
Installation, initial operation, operation and
maintenance must only be carried out by qualified
tradesmen
The installation and operating instructions, as well
as other valid documents must remain with the
user of the system
Content
1 General information . . . . . . . . . . . . . . . . . . . . . 7
2 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Transport, storage and packaging . . . . . . . . . 8
4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Construction and function . . . . . . . . . . . . . . . . 9
6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 12
10 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Illustr. 1.1 "Regumat M3-180 WMZ"
For an overview of our global presence visit
www.oventrop.com.
"Regumat S-180 WMZ" / "Regumat M3-180 WMZ" DN 25
Installation and operating instructions for the specialised installer
Valves, controls + systems

1 General information

1.1 Information regarding installation and operating
instructions
These installation and operating instructions serve the
qualified installer to install the heat meter connection
set professionally into the product group and to put it
into operation.
Other valid documents - manuals of all system
components, especially the operating instructions of
the circulation pump and heat meter, as well as valid
technical rules - must be observed.
1.2 Keeping of documents
These installation and operating instructions should
be kept by the user of the system.
1.3 Copyright
The installation and operating instructions are copy-
righted.
1.4 Symbol explanation
Safety guidelines are displayed by symbols. These
guidelines are to be observed to avoid accidents,
damage to property and malfunctions.
DANGER
imminent dangerous situation which will lead to death
or serious injury if the safety guidelines are not
observed.
WARNING
possible dangerous situation which may lead to death or
serious injury if the safety guidelines are not observed.
CAUTION
dangerous situation which may lead to minor or
moderate injury if the safety guidelines are not
observed.
NOTICE
damage to property which may occur if the safety
guidelines are not observed.
Subject to technical modification without notice.
135605080 12/2016
DANGER indicates
WARNING indicates
CAUTION indicates a possible
NOTICE indicates a possible
an
a
