Tool Specifications

Hand Circular Saw
Power consumption
Rated rpm (no load)
Speed pre-selection / Constant-Electronic
Starting current limiting
Spindle locking button
Saw blade Diameter
Hole
Tooth width
Blade thickness
Cutting depth 90°
45°
Cutting angle
Weight (without accessories)
Protection class

Operating Controls

1 Lock-off switch
2 On/Off switch
3 Spindle locking button
4 Sawdust ejector
5 Riving knife screw
6 Lever for swinging guard
7 Base plate
8 Swinging protective guard
9 Parallel guide
10 Protective guard
11 Winged screw for parallel guide
12 Cutting edge indicator
13 Winged screw for cutting angle adjustment
14 Scale
15 Grip
16 Speed control (CSP 68 E)
17 Allen key
18 Clamping screw
19 Clamping flange
20 Saw blade
21 Mounting flange
22 Riving knife
23 Motor spindle
24 Clamping lever for cutting depth setting
25 Cutting depth scale
Special Accessories (see appendix):
26 Guide rails
27 Screw clamps
28 Angle unit
29 Connection piece
Not all of the accessories illustrated or described are
included as standard delivery.
CSP 68 CSP 68 E
1300 W 1500 W
4800 min -1 1800 - 3800 min
•
–
•
–
• •
190 mm 190 mm
30 mm 30 mm
2,6 mm 2,6 mm
1,6 mm 1,6 mm
0...68 mm 0...68 mm
0...50 mm 0...50 mm
90°... 45° 90°... 45°
5,4 kg 5,5 kg
II / II /

Notes on Safety Prevention

Safe operation of this machine is possi-
ble only when the operating instructions
and the safety precautions are read
completely and the instructions con-
tained therein are strictly observed.
For further notes on safety refer to enclosed Sheet.
The machine is not qualified for operation in envi-
ronments where danger of explosion exists.
The machine must not be damp and must not be
operated in a wet environment.
Always inspect cable and plug before using
machine. Only have damage repaired by a qualified
professional.
The machine must not be operated without the
appropriate safety devices.
Always use the riving knife.
The swinging protective guard must be able to move
freely and must not be jammed in the open position.
The spindle locking button (3) may be pressed only
when the saw blade is at a standstill.
Put the plug into the mains socket only when the
machine is switched off.
Wear safety glasses, hearing protectors and protec-
tive gloves.
The dust that is produced while working is detri-
mental to health. Use dust extraction and wear a
dust mask.
Do not work with materials containing asbestos.
