Mounting the Angle Unit (CN-GRP)
The combination of the guide rail and the continuously
adjustable angle unit (28) makes possible exact angle
cutting, e. g., for fitting work. The angle unit is
mounted according to Figure . On the scale, the
required angle can be set.
When sawing with the PROTOOL GRP guid-
ing system, 5 mm is always to be added to the
necessary cutting depth.
Saw Table
Additional application possibilities are available with
the use of a saw table. Further information in this
regard is available from your dealer.
Storage
The unit should be stored in a dry place where it is pro-
tected against freezing.
Environmental Protection
Do not open worn out machines and return to the col-
lection facilities provided for recycling.

Maintenance

With each changing of the saw blade, remove
deposited saw dust from the inside of the protective
guard.
The ventilation slots on the motor casing should be
cleaned out from time to time.
After an operating period of approx. 200 hours, the fol-
lowing maintenance work must be performed:
Check the motor brushes and replace if necessary.
Clean the motor housing.
Renew the grease filling of the gearbox.
To verify that the protective insulation remains
intact, the machine must be subjected to a tech-
nical safety test afterwards. For this reason, this
work must be performed exclusively by a pro-
fessional electro-workshop.
Service
See enclosed sheet.
Guarantee
We guarantee PROTOOL appliances in accordance
with statutory/country-specific regulations (proof of
purchase by invoice or delivery note).
Damage attributable to normal wear and tear, overload
or improper handling will be excluded from the guar-
antee.
In case of complaint please send the machine, undis-
mantled, to your dealer or the PROTOOL Service
Centre for electric power tools.
Noise/Vibration Information
Measured values determined according to
prEN 50 144.
Typically the A-weighted noise levels of the tool are:
Sound pressure level: 101 dB (A).
Sound power level: 114 dB (A). Wear ear protection!
The typical hand-arm vibration is below 2.5 m/s
Declaration of Conformity
We declare under our sole responsibility that this prod-
uct is in conformity with the following standards or
standardization documents: EN 50 144-1,
EN 50 144-2-5, EN 55 014, EN 55 104,
EN 61 000-3-2, EN 61 000-3-3 according to the provi-
sions of the regulations 73/23/EEC, 89/336/EEC,
89/392/EEC.
Dr.ÊJosefÊLorenz
PROTOOL, Narex ‰esk‡ L'pa A.S.
47037 ‰esk‡ L'pa
Subject to change
