Pilot/Jog; Figure 7: Device View, Pilot/Jog - Geutebruck Pilot Bedienungsanleitung

Pilot/Jog

Front view
A key element for operation is the Jog/Shuttle, with an inner jog dial and outer
shuttle ring.
‰ On the side of the Jog/Shuttle and above it, buttons are also arranged that either
‰ At the top there is a USB port into which a USB memory device can be inserted.

Figure 7: Device view, Pilot/Jog

*Full particulars see chapter Configuring basic settings on page 42.
V 1.3
activate fixed functions or that can be freely assigned.
1 USB connection
2 Function keys F1-F4**
3 Keys, for example, for marking the beginning and end of a sequence
4 Jog dial disc
5 Shuttle ring
6 Home key
7 Mode key and key for toggling between maximized viewer and normal view
8 Keys, for example, to export a video sequence and for live play
