General Information - oventrop Multiblock TQ Einbau- Und Betriebsanleitung

EN
Read installation and operating instructions in their
entirety before installing the fitting
Installation, initial operation, operation and
maintenance must only be carried out by qualified
tradesmen
The installation and operating instructions, as well
as other valid documents must remain with the
user of the system
Content
1 General information ........................................... 7
2 Safety notes........................................................8
3 Transport, storage and packaging .................... 8
4 Technical data.....................................................8
5 Function..............................................................9
6 Installation ....................................................... 10
7 Accessories ..................................................... 12
8 Maintenance .................................................... 12
9 Warranty .......................................................... 12
Illustr. 1 Fitting "Multiblock TQ",
1
straight pattern G ⁄ male thread x G
2
Illustr. 2 Fitting "Multiblock TQ",
1
angle pattern G ⁄ male thread x G
2
For an overview of our global presence visit
www.oventrop.com.
Fitting "Multiblock TQ" for two pipe operation
Installation and operating instructions for the specialised installer
Illustr. 3 Design cover, straight pattern
Illustr. 4 Design cover, angle pattern

1 General information

1.1 Information
These installation and operating instructions serve
the installer to install the fitting professionally and to
put it into operation.
Other valid documents - manuals of all system
components as well as valid technical rules - must
be observed.
3
⁄ male thread
4
1.2 Keeping of documents
These installation and operating instructions should
be kept by the user of the system.
1.3 Copyright
The installation and operating instructions are
copyrighted.
1.4 Symbol explanation
Safety guidelines are displayed by symbols. These
guidelines are to be observed to avoid accidents,
damage to property and malfunctions.
3
⁄ male thread
4
Subject to technical modification without notice.
118407380
Valves, controls + systems
regarding
operating instructions
10/2016
installation and
7
