Machine elements

1 Mixing tools (identification marking)
2 HEXAFIX quick-action coupling
3 Guard handle
4 Handle

Technical data

Rated power/Current consumption:
Voltage:
Gears:
Rpm under load:
Mixing tool :
Spindle neck Ø:
Protection class:
Sound pressure level acc.to EN 50144:
Noise emission level acc.to EN 50144:
Hand-arm vibration:

Supplementary safety instructions

To be able to use the machine safely it is essential that you read these safety instructions thor-
oughly and comply with all of them.
The machine may only be used by persons who have familiarized themselves with the Operating Instructions
and all applicable regulations relating to work safety and the prevention of accidents.
In addition, you must also comply with the general safety instructions also included with the machine.
Take care to ensure that the current voltage indicated on the rating plate corresponds to that of the mains power
supply.
Do not use the device in any environments with potentially explosive atmospheres. Do not mix any solvents or solvent-
containing substances with a flash point of below 21° C / 70° F.
Do not wind cables or leads around any parts of the body.
Use only cables approved for outdoor use.
Start up and run down the machine in the mixing container only. Ensure that the mixing container is stood in a firm
and secure position.
Never insert hands or objects in the mixing tub while mixing is in progress. Risk of crushing!
If the sound pressure level should exceed 85 dB (A) where you are working, use ear protection! We recom-
mend that you wear work gloves and protective goggles when using the mixer. Regulations require that you
wear close-fitting clothing.

Intendend use

The machine is designed for the mixing of chemical building products of all standard viscosities (liquid, pasty, viscous,
powdery) used in the building industry and building-related trades. It is not to be used for the processing or preparation
of food or similar products.
The machine is not suitable for mixing for the mixing of food stuffs of materials containing graphite powder, hydrochloric
solutions or liquid manure. Mixing such materials can damage or destroy the machine.

Before using for the first time

Only use mixing tools with clean fitting ends.
Insert the mixing tools in the HEXAFIX coupling as far as is required for them to lock into place automatically. In doing
so, take care to ensure that the mixing blades are correctly positioned as shown on page 3. There should be
no contact between the mixing blades.
When fitting the mixing tools, also check that the identifying markings on the mixing blades match those of the mixing
shafts. For trouble-free operation the identifying markings (I + II) must match.
By swapping the mixing tools over the direction of mixing flow can be reversed. This can be useful for liquid materials.
Please note, however, that this will result in a higher load on the drive unit.
Connect the machine to the 220/230 Volt mains power supply.
5 Button for safety lock-off
6 ON/OFF switch with speed-control
7 Gear selector
8 Machine neck
CX 22 DUO
1000 W/4,4A
230 V /50-60 Hz
2
0 - 400 rpm
0 - 520 rpm
MKD 120
52 mm
/II
84 dB(A)
97 dB(A)
< 2,5m 2
CX 44 DUO
1400 W/6,2 A
230 V /50-60 Hz
2
0 - 350 rpm
0 - 500 rpm
MKD 140
52 mm
/II
84 dB(A)
97 dB(A)
< 2,5m 2
