Addressing

The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the LED BC-6 Beam Effect will respond to the controller.
Please, be sure that you don't have any overlapping channels in order to control each LED B-18 Beam Effect
correctly and independently from any other fixture on the DMX-chain.
If several LED BC-6 Beam Effects are addressed similarly, they will work synchronically.
Press the MODE button to select DMX controlled operation. When the Control Board shows d011, you can
select the desired starting address via the UP or DOWN buttons.
Now you can start operating the LED BC-6 Beam Effect via your lighting controller.

DMX-protocol

Control-channel 1 – Mode Selection
Value
000 - 063 Off
064 - 127 Sound controlled mode
128 - 191 Auto mode
192 - 255 DMX mode
Control-channel 2 - Red
Value
000 - 255 0 - 100%
Control-channel 3 - Green
Value
000 - 255 0 - 100%
Control-channel 4 - Blue
Value
000 - 255 0 - 100%
Control-channel 5 – LED effects
Value
000 – 031 RR-GY-BW-RRGY-RRBW-GYBW-RRGYBW
032 – 063 RR-GY-BW
064 – 127 RRGY-RRBW-GYBW
128 – 191 RR-GY-BW-RRGY-RRBW-GYBW-RRGYBW
192 – 223 RR-GY-BW
224 - 239 RRGY-RRBW-GYBW
RR-GY-BW-RRGY-RRBW-GYBW-RRGYBW
240 - 255
Control-channel 6 - Strobe
Value
000 - 063 Off
064 – 191 Automatic strobe
192 - 255 Sound controlled strobe
Control-channel 7 - Fade
Value
000 - 015 Off
016 – 223 Automatic fade
224 - 255 Sound controlled fade
Control-channel 8 – Motor rotation control
Value
000 - 095 No rotation
096 - 255 Controlled rotation
Function
Function
Function
Function
Function
Function
Function
Function
23/24
color selection
color change
color change
color change
sound controlled color change
sound controlled color change
sound controlled color change
