Connection with the mains

Connect the device to the mains with the power-plug.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.
Please note: A maximum of 8 LED BC-6 Beam Effect devices may be linked together. After every 8 LED
BC-6 Beam Effect devices, the fixtures must have a renewed connection with the power mains.

OPERATION

After you connected the spot to the mains, the EUROLITE LED BC-6 Beam Effect starts running.
The device has two operating modes. It can be operated in Stand Alone mode via the Control Board or it can
be run in DMX-controlled mode via a DMX controller.
The device features a built-in microphone and a rotary control on the device underside to adjust the sound
sensitivity.

Control Board

The Control Board offers several features: you can e. g. easily set the starting address or change program
modes.
The first digit on the Control Board shows the respective mode; the second and third digits on the Control
Board show the desired settings; the fourth digit on the Control Board shows the speed of the step motor.
Enter the menu by pressing the MODE-button. You can change the selection by pressing UP or DOWN. By
pressing the ENTER button, you can set the desired speed of the step motor (9 steps with increasing
speed). You can leave every mode by pressing the MODE-button. The functions provided are described in
the following sections.
The LED BC-6 Beam Effect features a memory function. The last program selected will begin anew when the
device is restarted.

- STAND-ALONE-OPERATION

• Setting solid colors and brightness
• Auto mode
Sound control mode
•
Slave mode
•

- DMX OPERATION

Stand Alone operation
In the Stand Alone mode, the LED BC-6 Beam Effect can be used without controller.
Disconnect the LED BC-6 Beam Effect from the controller.
