Overview
INSTALLATION
Rigging
When installing the device, make sure there is no highly-inflammable
material (decoration articles, etc.) within a distance of min. 0.5 m.
The device can be installed on the ground or on the wall or ceiling.
1.
Safety eyelet
2.
DMX IN
3.
DMX OUT
4.
Installation holes
5.
Fuse
6.
Power supply
7.
8. Microphone
Rotary control can be found on the underside of the
device.
R
T E
E N
N
W
D O
U P
D E
M O
8
7
DANGER OF FIRE!
18/24
LCD display with operating buttons
