12. It may be necessary to open the
central buckle of the pelvic brace again
in order to be able to easily push the
latches of the Click & Lock closures
into position. Afterwards, the central
buckle can be closed again.
13. Please consider the following when
closing the Click & Lock closure on the
panel: For all length settings (minimum,
maximum and in between) each of the
two pins must lock into one of the holes
in the bar. Only then the Click & Lock clo-
sures will sit flush against the orthosis.
In case the Click & Lock closure can later
not be locked completely, push or pull
the bar up or down a little, until both pins
have audibly locked into the next hole.
DynaCox evoluti o n
®
14. After pushing the latches flush against
the orthosis, any unintended opening
of the DynaCox evolution will not be
possible anymore. To open the Click &
Lock closures, insert an Allen key into
the opening on the back of the
closure (fig. 43), and push the latch
open (fig. 44). This opening can be
found on the closures on the femoral
panel and on the pelvic panels.
43
44
