Technician's Tipp:
In case there is a high degree of atrophy
on the patient's leg, doubling the
padding on the femoral panel may be
helpful to achieve a proper fit. An
additional pad can be ordered with
REF 23.604.050.00 (fig. 32).
• Fitting the Orthosis
on the Patient
Fitting the Orthosis
on a Standing Patient
Please note:
standing with slightly abducted legs
to allow for easier adjustment of the
DynaCox evolution.
1.
When putting the brace on the patient,
the upper edge of the femoral panel
should be placed directly below the
greater trochanter, and the lateral bars
should be positioned on the lateral
femoral center line.
2.
Close the bandage's pelvic hook-and-
loop closure (fig. 22).
22
3.
Now put the condylar clasp around
the patient's leg, and check the
34
position of the condylar pads. The
User Manual
evoluti o n
The patient should be
position of the condylar pads can be
adjusted step by step, by pushing the
pads further to the front or back of
the condylar clasp (fig. 23).
23
4.
Secure the position of the condylar
pads (1Nm), (fig. 24).
24
5.
Now close the pelvic brace of the
orthosis component (fig. 25).
25
If necessary, adjust the length of
the anterior and posterior belt again.
Minimal adjustments can also be made
