18
6.
To secure the bar's position, only push
the Click & Lock closure's lever in until
it just touches the femoral panel, but
do not push the lever all the way into
the cut-out on the panel
7.
Do not lock the Click & Lock closure
completely yet, so it remains possible to
make adjustments later on, if necessary.
In case the closure can later not be
locked completely, try to push or pull the
bar up or down a little while the Click &
Lock closure is already pushed in, so the
pins can audibly lock into a hole.
8.
Put the pads back into the pelvic
panels.
Attaching the Orthosis
Component to the Bandage
1.
Open the central buckle on the
anterior belt.
2.
Attach the orthosis component to the
bandage by pushing the pelvic brace
through the loop on the back of the
bandage (fig. 19).
DynaCox evoluti o n
®
19
3.
Now insert the femoral panel into the
pocket on the bandage (fig. 20).
20
4.
Close the zipper of the bandage over
the lower lateral bar (fig. 21).
21
5.
Close the hook-and-loop fastener on
the upper end of the pocket on the
bandage.
