3.5.2

Process connections, not front-flush

502
G 1/4 according to DIN EN 837
512
1/2-14 NPT according to DIN EN
837
504
G 1/2 according to DIN EN 837
(standard)
20 Nm
523
G 1/2 according to DIN3851 T11
70 Nm
3 Identifying the device version
30 Nm
25 Nm
511
1/4-18 NPT according to DIN EN
837
1/4-18 NPT
30 Nm
11
