DVANTAGES AND EQUIPMENT

Advantages of the two-cylinder system Caramatic Basic Two:
• automatic changeover to the gas cylinder on the reserve side as soon as the gas cylinder
on the operating side is empty
• the gas cylinder can be replaced without an operational interruption - withdrawal occurs only
alternately
• even gas supply through the optimum use of the gas cylinder content
• corrosion resistance in accordance with EN 16129, annex M (Use in maritime
environments)
Equipment of the two-cylinder system Caramatic Basic Two:
• central regulator
• with pressure relief valve PRV on the central regulator
• non-return gas valve: this means that gas escape is prevented when the gas cylinder is
changed
• medium pressure hose assembly (rubber with textile lining; resistant to cold temperatures
reaching -30 °C; hose dimension 6.3 x 3.5 mm) G 3/8 lh nut x G 3/8 lh nut x 400 mm to
connect the two regulators, brass connections, stainless steel compressive sleeves
• medium pressure hose assembly (rubber with textile lining; resistant to cold temperatures
reaching -30 °C; hose dimension 6.3 x 3.5 mm) G 1/4 lh nut x RVS 8 x 400 mm to connect
the system to the piping, brass connections, stainless steel compressive sleeves
• over fittings of 8 or 10 mm for connection to 8 or 10 mm piping
• combined fitting for optional connection to 5, 11 or 33 kg gas cylinders
• suitable for connection with a de-icer (not a recreational boat)
Check regularly that the sieve is not blocked. A blocked sieve may increase or
decrease outlet pressures. Clean or replace as required.
Pressure gauges on the central and changeover regulator
The pressure gauges
(ambient temperature-dependent) pressure of around 0 to 16 bar in the gas cylinder. If one of
the pressure gauges is at "0", the corresponding gas cylinder is empty.
part no. 02 018 51c
, changeover regulator
De-icer option (not for recreational boats
To prevent disruptions to the gas system during winter
operation, the two-cylinder system Caramatic Basic
Two can be connected with the de-icer 12 V (regulator
de-icing system) at the changeover regulator
Optional insect protection device
Insert in the breather on the 8 mm vent socket or screw into the female
thread G 1/8.
do not display the gas cylinder contents, they show the current
each with pressure gauge
Connection block for de-icer and pressure gauge
Caramatic Basic Two
)
.
5 / 12
