Housing for big lenses

Installing the housing

This section describes how to install the housing on
the wall bracket or on the Pan & Tilt head.
1. Sunshield mounting: screw the equipped
exagonal mounting spacers on the side-flanges
of the housing (Fig 6) in diametrically opposite
position in order to mount the sunshield above
the housing. Fit the sunshield on the housing
and fix it with the equipped screw on the
spacers.
2. Mount the housing on the wall bracket (Fig 8) or
on the Pan & Tilt head bracket (Fig 7).

TECHNICAL SPECIFICATIONS

Housing
-External dimensions:
-Internal dimensions:
-Weight:
-Material:
-Weatherproof:

Heater

-Power supply:
-Temperature ON:
-Temperature OFF:

Certifications

-Electrical safety (CE):
-Electromagnetic compatibility (CE):
-IP protection degree:
-EAC certification
6
228x211x720 mm / 9x8.3x28.3 in
(with sunshield)
116x116x562 mm / 4.5x4.5x22.1 in
(max. lenght)
116x116x477 mm / 4.5x4.5x18.7 in
(with circuit, Fig 4)
116x116x473 mm / 4.5x4.5x18.6 in
(with circuit, Fig 5)
13 Kg
Stainless steel AISI 316
IP67
12VDC-24 VAC, 20 W
110-240 VAC, 40 W
< 15°C ± 3°C
< 59°F ± 5°F
> 22°C ± 3°C
> 72°F ± 5°F
EN60065
EN50130-4, EN61000-6-3
EN60529 (IP66/IP67, with cable glands)
ENGLISH
