Mounting of EMB9341−E / EMB9342−E with fixing rails (standard)
4.2.2 Mounting of EMB9341−E / EMB9342−E with fixing rails (standard)
Mounting with fixing rails is only possible with the regenerative power supply module
EMB9341−E and EMB9342−E. The accessories required for mounting is included in the
scope of supply.
Dimensions
k
Fig. 4−3
a
EMB9341−E 135
EMB9342−E 135
EDBMB9340 DE/EN/FR 12.0
Regenerative power supply modules EMB9341 and EMB9342
g
c
c1
a
Dimensions of EMB9341−E and EMB9342−E for mounting with fixing rails
b b1 c
384 350 21.5
384 350 21.5
l
Mechanical installation
e
c1 d e
[mm]
92 365 250
92 365 250
4
9340vrm013
g k
6.5 30
6.5 30
91
