Note:
The coverage pattern can be changed to fit specific
requirements using the mirror masks. Mask off unused curtains
that are looking at walls or windows very close to the detector.
Under optimal conditions, the range of the detector can be up
to 100% higher than stated.
Walk test
Caution:
Each detector should be walk tested before
commissioning the installation.
The wireless PIR provides a walk test mode for testing the
detector operation and coverage pattern. Use the following
instructions to walk test the detector.
1.
Slide the custom insert to the top (see Figure 2, item 1).
2.
Using a screwdriver, carefully turn the screw to the left to
open the detector (see Figure 11, item 1).
3.
Create a tamper event by removing the device from its
mounting plate (Figure 11, item 2).
4.
Place the detector back on the mounting plate and turn the
screw to the right (Figure 11, item 3).
5.
Place back the custom insert at the top.
When the device is mounted again, the detector enters walk
test mode for approximately 3 minutes. The LED on the front
cover flashes to indicate an alarm event (Figure 11, item 4).
•
Walk test the detection pattern and make any necessary
adjustments with the adjustable blinders (see Figures 8
or 9).
•
Walk test the unit and verify the detector is communicating
with the control panel. See also the control panel
manufacturer's instructions.
Notes
•
Allow minimal 8 s of non-motion between individual walks
to allow the PIR to stabilize.
•
If the walk test period has timed out, the LED flashes
3X fast and the detector returns to normal operating mode.
In this mode the wireless PIR only supervises every
18 minutes, and the LED is disabled to reduce battery
consumption.
•
The fixed lockout time after an alarm is 3 minutes.
Detector maintenance
When installed and used properly, the wireless PIR provides
years of service with minimal maintenance. Walk tests should
be performed annually to ensure proper operation. See "Walk
test" above. Clean the cover with a damp (water) cloth to keep
it free of dust and dirt. Always test the detector after cleaning.
Replacing the battery
Remove the battery to reset the low battery signal before
installing a new battery. To prevent a low battery condition,
install the battery exactly as described in "Installing the battery
and first set up" on page 4. Replace with the recommended
batteries only (Duracell® DL123A, Panasonic® CR123A, or
Sanyo® CR123A). Use of any other batteries may present a
risk of fire or explosion.
P/N 466-2655 (ML) • REV A • ISS 17MAR16
Caution:
Batteries can explode or cause burns if
disassembled, recharged or exposed to fire or high
temperature. This device can be equipped with up to
3 batteries. If multiple batteries are used, replace all batteries
at the same time. Keep away from children. Dispose of used
battery according to battery directive instructions and/or as
required by local laws.
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
European
UTC Fire & Security hereby declares that this device
Union
is in compliance with the applicable requirements and
directives
provisions of one or more of the Directives
1999/5/EC, 2014/30/EU and 2014/35/EU. For more
information see www.utcfireandsecurity.com or
www.interlogix.com.
2002/96/EC (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information see: www.recyclethis.info.
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.interlogix.com/customer-
support or www.utcfssecurityproducts.eu
