5. If you are prompted to enter a PIN code, enter 0000. Certain devices require
that you also approve the connection.
6. Start playback on the connected device. You should now be able to hear the audio
from the connected device through the speaker, providing that the device is in range.
7. Turn the [ BLUETOOTH VOLUME ] (13) clockwise to the desired level and use
the [ MASTER VOLUME ] (8) control to adjust the main volume. Adjust
the volume level of any other used inputs, e.g. [ LINE IN VOLUME ] (1) and/or
[ MIC VOLUME ] (2) if needed. Turn them anti-clockwise to reduce or turn off their
input volume.

Wired connections

MIC IN
1. Connect a microphone or instrument to MIC IN (4). This combination microphone
input accommodates a Ø 6.3 mm jack plug with an unbalanced cable or
a XLR connector with balanced cable.
2. Turn the [ MIC VOLUME ] (2) clockwise to the desired level and use
the [ MASTER VOLUME ] (8) control to adjust the main volume. Adjust the volume
level of any other used inputs, e.g. [ LINE IN VOLUME ] (1) and/or
[ BLUETOOTH VOLUME ] (13) if needed. Turn them anti-clockwise to reduce
or turn off their input volume.
LINE-IN
1. Connect an external audio source to LINE IN (5) with a Ø 6.3 mm jack plug or to
LINE IN (6) with a RCA cable.
2. Turn the [ LINE IN VOLUME ] (1) clockwise to the desired level and use
the [ MASTER VOLUME ] (8) control to adjust the main volume. Adjust the volume
level of any other used inputs, e.g. [ MIC VOLUME ] (2) and/or [ BLUETOOTH
VOLUME ] (13) if needed. Turn them anti-clockwise to reduce or turn off their
input volume.
REC OUT
Connect an external recording device
or PA system to REC OUT (7) using
a RCA cable. The output signal will run
independent of the set master volume
or tone setting.
MIC IN
LINE IN
6
REC OUT
