10. PHILLIPS HEAD SCREW Use to remove the battery pack.
DRIVER
11. HANDPIECE COVERED Place Eye Shield over both.
BY BARRIER SLEEVE
12. EYE SHIELD This shield protects the eyes from the light
emitted from the light guide during use.
IV. Installation
IMPORTANT
• For proper operation, the power adapter and charger
base must be installed and used in a dry environment.
If the charger base becomes wet, unplug it immediately
and dry thoroughly before plugging it in and inserting the
handpiece.
• Do not place the handpiece into the charger base
until it has reached room temperature. Humidity and
condensation could damage the electronics.
• The power adapter is designed for use within a voltage
range from 100-240V, 50-60Hz. Ensure that the required
voltage is available before connecting the power cord
to the power adapter. Failure to do so may damage the
electronics.
• Use only the power adapter supplied by Coltène
the S.P.E.C. 3 LED Curing Light.
®
• Do not use the device unless the power cord is firmly
inserted into the electrical outlet.
Connecting the S.P.E.C. 3
®
1. Insert the power adapter cord (Fig. 5) into the receptacle
in the charger base (Fig. 4).
2. Place the charger base on a level and secure surface.
3. Insert the AC power cord (Fig. 6) into the power adapter
(Fig. 5).
LED Charger Base:
EN
4. Plug the other end of the AC power cord (Fig. 6) into an
electrical wall outlet.
5. Insert the handpiece into the charger base. Verify that the
charger base LED is illuminated orange which indicates
that the device is charging. An illuminated green LED
indicates the light is fully charged.
Charging the battery pack:
• The handpiece should be placed on the charger base
when battery is low or not in use.
• Before using the S.P.E.C. 3
time, please charge its battery for 24 hours.
• Make sure the handpiece is properly connected and
placed on the charger base. Do not force fit.
• When the battery is low or discharged, the handpiece
will not operate or maintain low power output. Place the
handpiece on the charger base immediately for 2-3 hours
before attempting to use.
• Charging in progress: ORANGE light is ON
• Charging complete: GREEN light is ON
NOTE: Do not operate the device while being charged on the
charger base.
with
®

4.1. Installation procedure

1. Gently insert the light guide into the opening on the hand-
piece. When light guide is fully inserted, approximately 1mm
of the metal ring will be exposed.
2.
Place the barrier sleeve over the curing light. Put the eye shield
over the end of the light guide drawing the barrier sleeve taut.
3.
Plug the AC power cord into the receptacle in the power
adapter.
4.
Connect the S.P.E.C. 3
Insert the plug on the power adapter completely into the wall
electrical outlet.
5. Keep the handpiece on the charger base when not in use.
LED Curing Light for the first
®
® LED Charger Base to the power adapter.
7
