Coltene S.P.E.C. 3 LED Benutzerhandbuch Seite 18

18
Guidance and Manufacturer's Declaration – Electromagnetic Immunity
The S.P.E.C. 3 LED Curing Light is intended for use in the electromagnetic environment specified below. The customer or the end user of the S.P.E.C. 3
®
LED Curing Light should assure it is used in such an environment.
Immunity Test
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
NOTE 1 At 80MHz and 800MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection
from objects, structures and people.
a. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and
FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the S.P.E.C. 3
Light is used exceeds the applicable RF compliance level above, the S.P.E.C. 3
abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the S.P.E.C. 3
b Over the frequency range 150kHz to 80MHz, field strengths should be less than 3V/m.
11.3 EN/IEC 60601-1-2: 2007 Table 4
IEC60601 test level Compliance Level
3Vrms 3Vrms
150kHz to 80MHz 150kHz to 80MHz
3V/m 3V/m
80MHz to 2.5GH 80MHz to 2.5GHz
EN
Intended Electromagnetic Environment
Portable and mobile RF communications equipment
should be used no closer to any part of the S.P.E.C. 3
LED Curing Light, including cables, than the
recommended separation distance calculated from the
equation applicable to the frequency of the
transmitter.
Recommended separation distance
d = 1.2√ P
d = 1.2√ P 80MHz to 800 MHz
d = 2.3√ P 800MHz to 2.5GHz
where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended minimum
separation distance in meters (m).
Field strengths from fixed RF transmitters, as
determined by an electromagnetic site survey (a),
should be less than the compliance level in each
frequency range (b).
Interference may occur in the vicinity of equipment
marked with the following symbol:
LED Curing Light should be observed to verify normal operation. If
®
S.P.E.C. 3 LED Curing LIght
®
Non-Ionizing Radiation
®
LED Curing
®
LED Curing Light.
®
®
