Owner's Guide
4. Slide an eye shield onto the light guide. This will hold the
polyethylene barrier sleeve taut over the tip of the light
guide and hold it in place ready for the next use.
5. Verify the polyethylene film barrier sleeve is still intact and
has not suffered damage such as tears or cuts. Store the
reassembled S.P.E.C. 3
location, preferably on the S.P.E.C. 3
so that the battery will be completely charged prior to the
next use.
LED Curing Light in a clean dry
®
LED charger base
®
EN
VIII. Technical Details
8.1. Power Supply
A. Input: 100V – 240V AC / 50 ~ 60 Hz
B. Output: S.P.E.C. 3
8.2. Dimensions
Component
Handpiece
Power Adapter
Charger Base
AC Power Cord
8.3. Environment
A. Operating Conditions
Temperature:
Relative Humidity:
Ambient Pressure:
B. Transportation and Storage Conditions
Temperature:
Relative Humidity:
Ambient Pressure:
: 6V DC, 2.5A
®
S.P.E.C. 3 ® Curing Light
174.5 × 24.8 (mm)
47 × 87 × 32 (mm),
136 × 86 × 60 (mm),
1.3M
-5°C ~ +40°C (23°F ~ 104°F)
10% ~ 85%
80 ~ 106 kPa
(23.62 inHg ~ 31.30 inHg)
-10°C ~ +45°C (14°F ~ 113°F)
10% ~ 90%
60 ~ 106 kPa
(17.72 inHg ~ 31.30 inHg)
13
