CHANGING THE OIL IN THE LOWER DRIVE (Fig. 9)
UK
viscosity SAE 80 ). Proceed as follows: A) loosen the screw cap (1). B) place the machine at an angle and suck up the oil using a syringe. C) fill up with
about 0.2 litres of new oil for the model of motor hoe with width 40 cm; about 0.5 litres for the model of motor hoe with width 50 cm.
To check the oil level: Place the machine in horizontal position; unscrew the cap and make sure the oil is at the lowest level of the hole. The filler and
emptying cap corresponds to the level of the oil.
SERVICING FOR THE HOE TILLERS
residues, grass, iron wires, etc. etc.
MAINTENANCE ENGINE (see engine manual)
overflows. Capacity O.500 kg approx. Use oil type MULTIGRADE viscosity to be 10 - 40 W.
GARAGING AND SCHEDULED MAINTENANCE
good machine working on safety conditions. Leave the machine to cool before garaging anyhow don't room it if the tank contains still contains some fuel as
the vapours could reach some blazes or sparks. To lower the fire danger , keep the engine , the silencer and the fuel area free from leaves , grass or greasy
substances.
DESCRIPTION OF THE MACHINE COMPONENTS (Fig. 8)
gear control lever. 4) Motor pull-start handle. 5) Cutting adjustment drewbar. 6) Cutters. 7) Cutter guard.

TECHNICAL DETAILS

cutter rotation speed is 120 rpm approx. Transmission : single speed or single speed+reverse speed. Weight of the complete motor hoe is 32 kg. Motor
hoe dimensions: max length 1.30 m max width 0.40 m height 1.10 m.
NOISE AND VIBRATION LEVEL
Handlebar vibration in compliance with EN and ISO 5349. Level max detected = 7,2 m/s
ACCESSORIES
8
Clean the tiller hubs, the tiller-shaft and the cutting hoe parts making sure they are free from soil
Motor: for details, see the specific publication. Working width of cutters is 40 cm, complete with protection guard. Top
Max noise level LWA = 89 dB (A).
1) Fixed-wing ridger with coupling. 2) Spring lawn weeder complete with guard. 3) Blade blower. 4) 16 cm cutter.
Generally speaking, the oil should be changed every 100 work hours (oil
Attention - The motor-cultivator is delivered without oil in engine. Replenish tank until oil
Keep attention that all the nuts ,screws and bolts are tightened in order to guarantee a
1) Accelerator control lever. 2) Hoeing start control lever. 3) Reverse
