GEAR BOX OIL CHANGE (only when engine/gear box is working using a hot device) (Fig. 13)
as a general rule the
oil should be changed after every 100 work hours (oil viscosity sae 80). to change oil: a) Remove the spur. b) unscrew the screw cap. - c) tilt the
machine and intake the oil through a syringe. - d) Pour in about 0,5 l. of new oil. tilt the machine to check that level is correct. the oil should begin to
flow from the hole just before the machine touches the ground (with point A) - e) Replace the filler screw cap (1).
ATTENTION! The used oil must not be drained into the sewer system or waterworks. In order to prevent any pollution to the water-table.
Most garages have used oil deposits, or use the authorized deposits according to your local authority regulations.
GARAGING AND SCHEDULED MAINTENANCE (Fig. 15)
Keep attention that all the nuts, screws and bolts are tightened in order
to guarantee a good machine working on safety conditions. leave the machine to cool before garaging anyhow don't room it if the tank still contains
some fuel as the vapours could reach some blazes or sparks. The fuel tank is to be drained outdoors only. To lower the fire danger, keep the engine,
the silencer and the fuel area free from leaves, grass or greasy substances. Periodically check the tightness of the handlebar (1) to the support (2).
if the tightening is not guaranteed, please lower the lever (3) and tighten the nut (4).
DESCRIPTION OF CONTROLS (Fig. 14)
1. throttle lever - 2. Hoeing gear control lever (safety feature) - 3. Reversing lever - 4. tilling
adjustment spur (single position) - 5. Cultivator blade (with enlargement) - 6. Knobs handlebar/frame - 7. Handlebar - 8. transport Wheel - 9. Hoe
shield - 10. Pull-out handle (self-winding device) 11. motor – 12. lock/release lever for handlebar – 13. Handlebar support

TECHNICAL SPECIFICATION

Engine: consult the specific publication for information. Transmission: primary by belt, secondary by chain.
Tiller: fitted with interchangeable hoes. Working width 50 cm and 75 cm. The highest speed of rotation of the tiller is about 140 R.P.M. Transmission :
single speed or single speed + reverse speed. max length: 1,35 m. max width: 0,50 - 0,75 m. Height: 1,00 m. Package dimensions: long 80 cm - wide
53 cm - high 69 cm.
NOISE AND VIBRATION LEVEL
measured sound pressure level with en709, leq = 88,5 dB (a), with a uncertainty value K = ±0,8 dB (a).
measured sound power level with en709, lwa = 96,1 dB (a), with a uncertainty value K = ±0,9 dB (a).
Handlebar vibration in compliance with en 709 and iso 5349. level max detected = 5,39 m/s , uncertainty value K = ±0,36 m/s .
2 2

ACCESSORIES:

Ridging plough and de-thatcher.
