Specifi cations (continued)
Monitoring
Description:
Monitoring Instrument
Functions:
Output:
Correlator
Description:
Correlator Instrument
Display:
Scale range:
Standard color setting:
Attack/release time:
EN-90 9 | Specifi cations
The Monitoring instrument provides a monitoring control
function which enables monitoring of displayed audio sig-
nals.
• Monitor level control with onscreen level fader
• Mute, Dim
• Internal Downmix for multichannel monitoring, audio
output of monitoring signals via S/PDIF out connector.
Digital 2-ch. Stereo (S/PDIF out, unbal., RCA-F)
Stereo Correlator instrument for displaying the phase rela-
tionship between the two channels of a stereo signal and
thus its mono compatibility.
Bargraph, additional spot indicator between PPM bar-
graphs
–1 r to 0 to +1 r
red: –1 r to –0.1 r
white: 0 r (–0.1 r to +0.1 r)
green: +0.1 r to +1 r
1.0 s/2.5 s
