Specifi cations (continued)
Digital Peak-/TruePeakmeter
Word width:
Digital scales:
Headroom:
Integration time (Attack): acc. to standard: Sample (Dig60), 4x oversample (TP60),
MC - Moving Coil
Description:
Moving Coil Instrument
Modes:
PPM Mode
- Ch. arrangement:
- Scale:
- Integration time:
VU Mode
- Ch. arrangement:
- Scale analog:
- Scale digital:
- Lead:
Manual | TM3-Primus
24 bit
• TP60: +3 .. –60 dB
• Dig60: 0 .. –60 dB
• Nordic: +12 .. -42 dB
• BR IIa: 7 .. 1 (British)
• VU
–9 dBFS, beginning (turning red) at:
• –9 dBTP on TP60 scale
• –9 dBFS on Dig60 scale
• +6 dB on Nordic scale
• "6" on BR IIa scale
10 ms (Nordic), 20 ms (BR IIa)
Moving Coil instrument for the display of needle instru-
ments for 2-channel Stereo with different modes and
scales.
PPM (BR IIa), VU, PPM (BR IIa) + Loudness (L/R + I)
Stereo horizontal, Stereo vertical
BR IIa: 7. .1
20 ms
Stereo horizontal, Stereo vertical
VU (–20 to +3 dB)
VU Digital (–20 to + 3 dB)
0 dB, adjustable from 0 to 10 dB in steps of 1 dB
