4.5 | MC – Moving Coil
Instrument
Moving Coil im PPM-Modus
Needle instru-
ment for left
channel
Channel
designation
and Over
indicator
Moving Coil in VU mode
The Moving Coil instrument features a genuine emulation of various mo-
ving coil level meter types, including PPM, VU, or PPM + Loudness mo-
des. Depending on selected mode and standard, the L and R channels of
a stereo signal can be displayed in two separate moving coil instruments
(PPM, VU) or in one single (PPM + Loudness).
EN-48 4 | Instruments | 4.5 | MC – Moving Coil
Moving Coil in PPM + Loudness mode
Needle instru-
ment for right
channel
Channel
designation
and Over
indicator
Needle instru-
ment for both
channels +
Loudness
Relative Loud-
ness scale,
center acc. to
Target Level
I value desi-
gnation
