9 | Specifi cations
System
General
Power requirements:
Current drain:
Display:
Connectors:
Dimensions (W x H x D): 82.5 x 138 x 50 mm
Weight:
Operating temperature:
Functions
EN-80 9 | Specifi cations
+5 V DC via USB Micro B connector
400 mA nominal, power-up current is much higher
Capacitive 4.3'' touch screen (272 x 480 pixel)
1 x USB Micro-B; USB 2.0 Full Speed connector for data
exchange between computer applications and TM3-
Primus, and for power supply via computer or external
mains adapter
2 x RCA-F, analog in (unbalanced, adjustable)
1 x RCA-F, S/PDIF in (unbalanced)
1 x RCA-F, S/PDIF out (unbalanced)
approx. 320 g w/o mains adapter
+5° to +40° C
• Operation with one fi nger (touch sensitive display)
• Optimized screen layout with selectable instruments
• Multiformat PPM/TruePeak for 2-ch. Stereo (analog,
digital, PC audio via USB) and 5.1 Surround signals (PC
audio via USB)
• Loudness acc. to ITU-R BS.1770-3/1771-1, EBU R128,
ATSC A/85, ARIB, OP-59, AGCOM, CALM Act
• Loudness Chart instrument
• Loudness Range instrument (Magic LRA)
• Moving Coil (BR, VU, BBC mode)
• Stereo Correlator
• 1/3-octave spectrum analyzer (RTA)
• 2-channel Audio Vectorscope
• Monitoring (with onscreen level fader)
• Numerical displays
Manual | TM3-Primus
