4.9 | Numeric Instrument

Instrument
Current Momentary-
value M
Current Shortterm
value S
Current Integrated
value I
Current LRA value
Maximum True Peak
value TPmax
The Loudness Numeric instrument provides numerical readouts of the
following loudness measurements:
• M (Momentary): Summed momentary loudness measurements of the
• S (Shortterm):
• I (Integrated):
• LRA:
• TPmax:
If needed, the numerical readouts of these individual loudness measure-
ments can be activated or disabled individually. The values of current run-
ning measurements for I, LRA, and TPmax values will be colored green,
those of stopped measurements yellow. If values are exceeding the upper
limits, they will be colored red.
EN-58 4 | Instruments | 4.9 | Numeric Instrument
individual channels using an integration time of 400
ms.
Summed loudness measurement using an integration
time of 3 s and a sliding window.
Overall program loudness between start and end
points that are entered manually. Use the Start, Stop
and Reset Loudness buttons to execute this measu-
rement.
Loudness Range
The highest measured True Peak value in dBTP
State of the measure-
ments:
green: running
yellow: stopped
red: exceeded
