Specifi cations (continued)
VSC - Vectorscope
Description:
Audio Vectorscope Instrument
Display mode:
Inputs:
AGC:
Grid:
RTA
Description:
Real Time Spectrum Analyzer (RTA) Instrument
Functions:
Input sources:
Frequency range:
Number of bands:
Weighting fi lter:
Peak hold indicator:
Measuring range:
Resolution:
Reference:
Integration time (ballistics): Fast
Manual | TM3-Primus
2-ch. Audio Vectorscope for displaying the phase relati-
onship between the channels of a channel pair (Lissajous
display).
2-channel
L/R
fast
L/R
Real Time Spectrum Analyzer instrument for displaying
the spectral content of the input channels using 31 fi lter
bands. Highpass fi lter for High Band (>20 kHz).
• Peak hold on/off
• Set reference
• Selectable resolution
Stereo pairs
20 Hz to 20 kHz, highpass fi lter for High Band (>20 kHz)
1/3-octave: 31 bands, fi lter acc. to IEC 225 class 2
Linear
4 s, 2 s, off
45 dB max.
3, 6, 9 dB
0.0 dB; adjustable from 0.0 to 21.0 dB in steps of 1 dB
