Specifi cations (continued)
PPM + Loudness Mode
- Ch. arrangement:
- Scales:
Loudness Bar/Numeric instrument
Description:
Common Loudness Parameters
Loudness Sum display:
Loudness Num display:
Weighting fi lter:
Level settings for summation
(channel weighting):
TruePeak Over Threshold: –1 dBTP; adjustable from 0 to –4 dBTP in steps of 1 dBTP
EN-84 9 | Specifi cations
Dual-PPM with additional Loudness display (BBC) for I in
one instrument
• PPM: see above
• Loudness: +9 to –9 LU fi xed (mid of scale corresponds
to Target Level)
Loudness Sum and Loudness Num instruments for dis-
playing the summed loudness values M, S, or I of a loud-
ness measurement acc. to EBU R128, ITU BS.1770-3/
1771-1, ARIB, ATSC A/85, OP-59, AGCOM, CALM Act
on a bargraph resp. on a numerical display.
One Loudness bargraph selectable:
• M bargraph (Momentary - summation of momentary
loudness values of all channels for a short span of time)
• S bargraph (Short - loudness summation value of a
dynamic time frame)
• I-Bargraph (Integrated - long term loudness value
infi nite or manual control)
• Onscreen keys for measurement operation: Start, Stop,
Reset Loudness
M, S, I, TPmax, LRA values, selectable
K fi lter acc. to ITU BS.1770
• 0.0 dB (L, R, C)
• +1.5 dB (LS, RS)
• Off (LFE)
