This section provides a comprehensive installation and operation guide which will
assist with the commissioning of the 8175 Level Transmitter.
2.1

INSTALLATION

Pay attention to the installation of the transmitter to ensure the proper
operating of the device.
Select the mounting position by respecting the following instructions:
H
min. 30 cm
Protect the device against bad weather and temperature changes:

QUICKSTART

H
min. 30 cm
≅ R/2
Mounting on a closed tank
D
Protection when installed outside
H
min. 30 cm
≅ R/2
D (mm) 65
H (mm) 100
Mounting on a shaft
4
80 100
250 400
