PRODUCT DESCRIPTION

3 Product description

3 1 GENERAL

The device is an electromechanical linear drive. It performs linear
movements.
1
Fig. 1 Patio linear drive
Fastening piston side (fork head)
1
Fastening housing (fork head)
2
Connection cable
3

3 2 TECHNICAL DATA

All information in this section assumes an ambient temper-
ature of 20°C.
8 – ENGLISH

3 2 1 Summary of the technical parameters

Technical data
Rated voltage
Force, dynamic (N)
Force, static (N)
Stroke speed (mm/s)
Stroke length (mm)
2
Rated current (A)
Output (W)
Duty cycle
Type of protection
Cable length
Temperature range
Limit switches
Connecting rod
3
Airborne noise emission
Weight
Tab. 1 Technical parameters
1) Option without deactivation: If there is a blockage, the control unit must switch
off the current supply within 10 seconds in order to avoid overloading the drive.
Observe changeover time of at least 2 seconds.
2) Discrepancies in technical data possible.
3) Noise level 60 dB(A) (with nominal power and without load in accordance with EN
ISO 3745)
PATIO1515
24 V DC
1.500
1.200
approx. 6
150
approx. 2.3
(1)
55
S3 15%
IP 65
1,5 m
-10°C - +60°C
(2)
Limit stop deactivation
Secured against rotation
> 60 dB (A)
(3)
up to 1.5 kg
