Matrix ROWER-02 Bedienungsanleitung Seite 9

Black Hardware Pack
1
Description Qty
A Bolt 2
A
Rotate console
mast up 30
degrees
Orange Hardware Pack
2
Description Qty
B Flat Washer 2
C Bolt 4
D Arc Washer 2
Note:
Tighten hardware from step 2
using the Torque Value:
24.5 Nm / 18 ft-lb
C
B
D
9
