Matrix ROWER-02 Bedienungsanleitung Seite 11

White Hardware Pack
5
Description Qty
I Bolt 6
Note:
Tighten hardware from step 5
using the Torque Value:
24.5 Nm / 18 ft-lb
6
I
Pre-installed Hardware
Description Qty
J Flat Washer 2
K Stopper Left 1
L Stopper Right 1
M Bushing 2
N Bolt 2
Note:
Tighten hardware from step 6
using the Torque Value:
24.5 Nm / 18 ft-lb
K
ASSEMBLY COMPLETE!
N
J
M
L
11
