Area of application

The RPS repair kit with repair balloons functions as a reliable barrier against
residual water discharging from the pipe. It therefore keeps the work area dry
while a electrofusion welding is being prepared for the repair of damaged or
for the integration of new HDPE drinking water pipes (nominal diameters
d 90 - d 900).
These operating instructions apply in connection with the FRIALEN and
FRIALEN XL assembly instructions.
The following Table 1 lists the FRIALEN and FRIALEN XL components needed
to close the drill hole.
Pipe size
[mm]
90 -180
200 - 225
250 -315
355 - 450
500
560
630
710
800
900
Table 1
Repair FRIALEN / FRIALEN XL
balloon type components for closing
Typ 1
Typ 2 VVS d 200 - 225
Typ 2 VSC-TL d 250 - 315
Typ 3 SA-XL d 355 - 450/225
Typ 4 SA-XL d 500/225
Typ 4
Typ 5
Typ 6
Typ 7
Typ 8
the drill hole
VVS d 90 - 180
RS-XL d 560
RS-XL d 630
RS-XL d 710
RS-XL d 800
RS-XL d 900
Required clamping
equipment
Clamping unit
FRIATOP
Clamping unit
VACUSET XL
Clamping unit
VACUSET XL
Tensioning belt installation
Tensioning belt installation
Tensioning belt installation
Tensioning belt installation
Tensioning belt installation
