Installation
Note for IR 180 AP: 7. Push through sealing
The installation position plugs and pass the ca-
should be at least 1 m from ble through (the cable
a light, since heat radiation sheath must be comple-
may trigger the system. tely surrounded by the
sealing plug).
Installation procedure:
1. Loosen housing screws Connecting the supply
and open housing , lead to the basic element
then loosen sensor unit (refert to ill. on page 4):
(screw) and remove The mains lead consists of
with the basic element a 3 phase cable.
. L = phase conductor (usu-
2. Hold base of housing on ally black or brown)
wall (with the inscription N = neutral conductor
TOP facing upwards) (usually blue)
and mark the drilling L' = phase conductor (usu-
holes. ally black or brown)
3. Drill holes with a 6 mm If in doubt, the cable must
bit. be identified with a voltage
4. Insert dowels in the tester. Switch off the cur-
holes. rent again. Phases (L) and
5. Screw the base of the (L') in addition to the neu-
housing in place with the tral conductor (N) are con-
enclosed screws. nected to the terminal
6. Strip the cable (approx. block. A protective-earth
70 mm) and remove conductor is not required.
approx. 5 mm of insula-
tion from the flexible Important: Reversing the
ends. connections may result in
damage to the unit.
16
Functions
8. Insert basic element
into the housing section
(terminal connection
at bottom).
9. Carefully push on the
sensor module (tak-
ing care not to jam) and
screw to the housing
base section.
10.After the mains connec-
tion has been made, the
sensor switch can be
operated (refer to func-
tions section).
11. Finally apply the design
shade and screw in
Functions
place.
Note:
Parallel switching of
IR 180 AP and HF 360 AP
is possible. Nevertheless, a
neutral lead must be pres-
ent on each flush box. The
max. output to be switched
does not increase as a re-
sult.
Reach setting
(Sensitivity)
The term reach denotes the
approximately circular
diameter that results as the
detection zone.
1 - 8 m
Twilight setting
(Response threshold)
The desired sensor re-
sponse threshold can be
2
2
adjusted continuously from
lux
approx. 2 lux to 2000 lux.
LUX
Adjusting screw right stop
position means: daylight
operation approx. 2000 lux
(factory setting).
2 - 2000 lux
Time setting
(Switch/off delay)
The desired duration of illu-
mination of the connected
light can be continuously
adjusted from approx.
30
10 sec. to max. 30 min.
Adjusting screw left stop pos-
ition means: shortest time
approx. 10 sec. (factory set-
ting)
10 sec. - 30 min.
Adjusting screw right stop
position means: longest
time approx. 30 min.
The timer is restarted by
any motion detected before
this time elapses.
(only for HF 360 AP)
Adjusting screw left stop
position means: minimum
reach (approx. 1 m / factory
setting).
Adjusting screw right stop
positon means: maximum
reach (approx. 8 m).
Adjusting screw left stop
position means: night-time
operation approx. 2 lux.
When adjusting the detec-
tion zone and for the per-
formance test in daylight, the
adjusting screw must be set
to the RH stop position.
The shortest time setting is
recommended when adjus-
ting the detection zone and
performing a functional test.
Note: After every off switch-
ing, further motion detection
is interrupted for approx.
2 seconds. Only after this
time elapses is it possible
for the Sensor Switch to
switch light again.
