7.3
Mit Klemmenkasten
7.3.1

Kabelanschluss

7.3.1.1
Schritt 1
7.3.1.2
Schritt 2 und 3
Zur Gewährleistung der angegebenen
Schutzart sind nur geeignete Kabel-
durchmesser zu verwenden.
* Siehe Seite 7 oder 9
See page 7 or 9
MB049 - 11114026
Baumer_HOG22_II_DE-EN (18A2)
Elektrischer Anschluss / Electrical connection
*
*
10
11
TX 20
22 mm
*
*
13
14
TX 10
7.3

With terminal box

7.3.1

Cable connection

7.3.1.1
Step 1
12 *
7.3.1.2

Step 2 and 3

To ensure the specified protection of
the device the correct cable diameter
must be used.
7
12 *
*
20
ø5...13 mm
18
