8. Setting up unit using PC software
Hint: The preset storage cycle influences the storage capacity
(see chap. 11).
- Set-up possibility, only in "Limit"
Data storage is only in the case of set point limit condition.
- Set-up possibility "External control"
Here the analogue value recording is started and stopped by
an external input signal.
Digital input Low —> Storage and integration not active.
Digital input High —> Storage and integration active.
8.1.5 Stirage cycle
Here the storage cycle for the analogue value and counter can
be set up (1 minute to 24 hours).
Hint: The preset storage cycle influences the storage capacity
(see chap. 11).
8.1.6 Display
Set-up possibilities "Display". Here the data logger values that
are to be indicated on the display can be set up. Here the
set-up of scroll or frozen display can also be selected.
The following set-up selection is possible:
Scroll (The display changes in a 5 second display cycle):
- Analogue value —> digital value -> time (factory default)
- Analogue value —> time
- Analogue value —> digital value
- Digital value —> time
Frozen:
- Only analogue value
- Only digital value
8.1.7 Unit address
Each unit that is operated using the serial interface must have
an individual serial unit address (00 - 99).
